Built for Thrilling Off-Road Expeditions
Mike’s 2002 Supercharged Toyota Tacoma Double Cab 4×4 embodies a passion for conquering the toughest terrains. Rooted in a legacy of rugged off-grid survival from the 1960s, it stands as a testament to adventure and resilience, equipped to tackle snow, mud, sand, water, and rocks with unmatched capability.
Experience the Thrill of Off-Road Mastery
Discover the exceptional engineering and rugged design that empower Mike’s Tacoma to conquer the toughest landscapes with unmatched reliability and style.
Supercharged 3.4L V-6 Engine
Delivers robust power and torque, ensuring peak performance across all extreme terrains.
Solar-Powered LED Light Bar
Provides eco-friendly illumination for night expeditions and harsh weather conditions.
Advanced Suspension System
Engineered for superior handling and comfort on unpredictable off-road trails.
Integrated HAM Radio & VIPER Alarm
Equipped with reliable communication and security features for remote adventure safety.
learn all about my 4×4
2002 TRD Toyota Tacoma 4X4 Double Cab:
1. 3.4L V-6 Supercharged Engine with URD 7th Injector Kit for TRD/Magnuson 5VZ-FE Supercharger / OEM Pro-Dry Filter, 5VZ-FE 3.4L V6, 95-04 Tacoma, V6.
2. VIPER Alarm System with auto electronic shut down and Viper GPS tracking.
3. Garmin IR SHOCK Sensor, Front / Rear Camera, Stock AM/FM, Cassette, CD Stereo system.
4. Front ARB Locking Differentials, and Rear TRD Locking Differentials / 4.88 Gears / ARB 4-way breather extensions to Rear Differential – Transmission – Front Differential and Gear Box.
5. VIN matched (2) Magna Flow Cats – worthless to thieves!!
6. Safari Snorkel.
7. Front King Shock Coil-overs / Rear Bilstein Shocks with reservoirs.
8. WARN 96805 VR 8-S Winch / 100 Ft X 3/8” Synthetic Winch 26,500 Lb. Rope / Warn 90287 Wireless Remote for Truck / Ultra-HOOK Factor 55 with a max load of 16,000 Lb. Spare 100’ Steel Winch Cable.
9. Custom LEER Aluminum Shell designed with a curved design for less wind resistance, so the Tail gate can be closed while the rear door with Solar Panels attached can be in the up position, clearing the High Lift Jack.
10. ARB Awning equipped with ARB Tent with bug screen, ceiling, floor, zip-up doors.
11. Licensed GMRS and HAM Operator by FCC / Cobra BT-CB / Weather Station and Kenwood TM-V71 Mobile Ham Radio.
12. 20# CO2 Tank with a 5-gallon air tank under the bed, complete with F/R connections. (This design helps fill 4 tires in under 5 minutes at 120 psi and operates all air tools.
13. Tuffy Console.
14. BF Goodrich TKO2 AT 285/75R16 tires x 5 (spare).
15. Yellow Top Optimum Battery.
16. Custom DeMello Swing Gate with Hi-Lift XT-485 Jack and cover. Shovel and Ammo Box (complete with fluids inside) attached.
17. Custom All-Pro Rock Guards welded to the frame.
18. Drilled and Slotted Front Rotors with extra-thick Ceramic Pads.
19. Solar System: Go Power! GP-SW3000-12 3000-Watt Pure Sine Wave Inverter, 260w Monocrystalline Solar Panels, with 200ah Lithium-Ion Phosphate Battery, MPPT Solar Controller to manage energy, Renogy 12v DC-DC Charging system, both with Bluetooth technology. In addition to control (2) 110v A/C fans that cool the batteries once they reach 100 degrees, I use a second Pure Sine 400w Inverter to control the fans via Bluetooth to the MPPT controller.
20. Solar Operated: 18,000 Lumen – LED Light bar attached in front on top of Shell Rack, (2) 1875 Lumen – LED Waterproof Rock Lights under body; (2) R/L Side of Shell, (2) Rear of Shell, (2) in front of truck facing right – left for road guidelines and (2) in front facing forward for fog.
21. Custom-made wood sliding 6-sectional toolbox in bed, complete with 7-day supply of MREs; Reinforced drive shaft; Spare Half shaft with Center Support Bearing; Spare Drive Shaft; Spare CV Axle; Air Tools with cutting equipment; Mechanic Tools Sets Metric/Standard; Engine Electronics with spare headlamps and coils.
22. Shell Toolbox contains the Solar System and extra Wire, Fuses, Duct Tape, Screws, Nuts & Bolts; FRS Radios; small tools, and Soldering Station.
23. ARB Recovery Bag complete with extra Snatch Blocks, Tow Straps / Bubba Kinetic Rope.
24. Rhino Lining trim – top and sides.
25. D-Ring 1/2″ Tie Down, Welded.
26. Custom fit, Trailer Power Connection through the rear bumper.
27. 10-gallon pressurized water tank system for shower, using a Propane heater, and a 10-gallon gas container.
28. (3) Tool Bags complete with Rope/Straps, Electronics/Wire, and Larger Nuts & Bolts.
